Self-balancing robot version 3 update!


It works! Now it balances on hard or soft floors for more than 30 minutes!



What changed?

Firstly, 2xAA rechargeable Eneloop batteries are insufficient to power those FS90R motors. The specification of the motor allows up to 6V. Two cells provide only around 2.7V total. I switch to 4xAA Eneloop batteries, providing around 5.4V. The motors were much much faster, more than twice as fast. The immediate consequence of this is that the PID parameters need to be re-tuned and scaled down to 10-20% of the values for 2xAA batteries.

Secondly, I turned up the builtin digital low pass filter in the MPU-9250 aggressively. Now it is set to 5 for both accelerometer and gyroscope. That translates to a sensor delay of 17ms and the 3dB bandwidth of about 10Hz. That is probably averaging around 17 samples at 1kHz sample rate. And that did the trick!

Here's a graph of motor power, gyroscope angular velocity and tilt angle.


The filtered angular velocity seldom exceeds 0.3 degrees per second. The filtered tilt angle seldom exceeds 1 degree. The motor power is mostly less than 10% of maximum power.

I've updated the InvenSense MPU-9255/MPU-9250/MPU-6500 module. You can now specify the low pass filter level for the accelerometer and gyroscope in the call to InvMPU.reset_mpu(). Copy this new version into your custom.ts.

The only changes from the version 1 code are the PID tuning parameters and the call InvMPU.reset_mpu(5, 5).

See the previous post on the parts for building version 3.



Thursday, November 16, 2017

Self-balancing robot version 3


Version 1 was made out of Lego. It keeps breaking into pieces, the motors were not secured and it also contained the unnecessary Kitronic servo:lite board. So, I rebuilt it.

Parts:

The code for this version is identical to the code for version 1 except the tweek for a different orientation of the MPU-9255. With 2x AA batteries, identical PID parameters will work. With 4x AA batteries, the parameters have to be retuned.

But, alas, it still doesn't balance well on smooth hard floors!

It works fine on carpet or cushion even though it is only half the height of the version 1 robot. It just won't work on wood or marble floors!

After much tuning, I decided to record the motor response. I added two more wheels and turned the bot into a "car". Then I recorded the horizontal acceleration using the accelerometer in response to various motor control like a 1 second 66% power pulse. Here is a typical result with 2x AA batteries:


Why is the acceleration oscillating around zero? The amplitudes of the oscillations are much worse with 4x AA batteries.

Oh, the motor controller in the servo is a closed loop controller!

The closed-loop controller inside the FS90R is probably a variant of the standard PID controller. The oscillations are caused by the controller trying to match the output voltage to the pulse duration.

The accelerometer and gyroscope are picking up physical feedback from the controller's actions. On soft floor like carpet, the feedback is dampened physically. On hard floors, the sensors pick up random spikes that throws the PID algorithm off.

On top of that, the accelerometer only picks up the increase in motor speed after about 60ms!

In short, don't build a self-balancing robot using servo motors. Just use DC motors.

Update: I've fixed the problem and got it to work on hard floors too!
